Shelving Sizes
Starter Kits
Tubular Shelving
Approx. Ship
Wt
Add on Kits”
Tubular Shelving
Approx.
Ship Wt
(in) (mm) (lb) (kg) (lb) (kg)
3 SHELF UNITS
18” Deep Shelves with 21” Deep Uprights
18x36 457x914 SCASS-1836-3-SU 59 27 SCASS-1836-3-AU 63 29
18x48 457x1219 SCASS-1848-3-SU 69 31 SCASS-1848-3-AU 73 33
18x60 457x1524 SCASS-1860-3-SU 79 36 SCASS-1860-3-AU 83 38
21” Deep Shelves with 21” Deep Uprights
21x36 533x914 SCASS-2136-3-SU 62 28 SCASS-2136-3-AU 66 30
21x48 533x1219 SCASS-2148-3-SU 72 32 SCASS-2148-3-AU 76 34
21x60 533x1524 SCASS-2160-3-SU 85 38 SCASS-2160-3-AU 89 40
24” Deep Shelves with 24” Deep Uprights
24x36 610x914 SCASS-2436-3-SU 65 29 SCASS-2436-3-AU 69 31
24x48 610x1219 SCASS-2448-3-SU 78 35 SCASS-2448-3-AU 82 37
24x60 610x1524 SCASS-2460-3-SU 88 40 SCASS-2460-3-AU 92 42
4 SHELF UNITS
18” Deep Shelves with 21” Deep Uprights
18x36 457x914 SCASS-1836-4-SU 69 31 SCASS-1836-4-AU 73 33
18x48 457x1219 SCASS-1848-4-SU 82 37 SCASS-1848-4-AU 86 39
18x60 457x1524 SCASS-1860-4-SU 95 43 SCASS-1860-4-AU 99 45
21” Deep Shelves with 21” Deep Uprights
21x36 533x914 SCASS-2136-4-SU 73 33 SCASS-2136-4-AU 77 35
21x48 533x1219 SCASS-2148-4-SU 86 39 SCASS-2148-4-AU 90 41
21x60 533x1524 SCASS-2160-4-SU 103 47 SCASS-2160-4-AU 107 49
24” Deep Shelves with 24” Deep Uprights
24x36 610x914 SCASS-2436-4-SU 77 35 SCASS-2436-4-AU 81 37
24x48 610x1219 SCASS-2448-4-SU 94 42 SCASS-2448-4-AU 98 44
24x60 610x1524 SCASS-2460-4-SU 107 48 SCASS-2460-4-AU 111 50
Shelving Sizes
Starter Kits
T-Bar Shelving
Approx.
Ship Wt
Add on Kits
T-Bar Shelving
Approx.
Ship Wt
(in) (mm) (lb) (kg) (lb) (kg)
3 SHELF UNITS
24” (610 mm)Deep Shelves24” Deep Shelves with 24” Deep Uprights
24x36 610x914 SCASCH-2436-3-SU 59 27 SCASCH-2436-3-AU 63 29
24x48 610x1219 SCASCH-2448-3-SU 66 30 SCASCH-2448-3-AU 70 32
24x60 610x1524 SCASCH-2460-3-SU 73 33 SCASCH-2460-3-AU 77 35
4 SHELF UNITS
24” Deep Shelves with 24” Deep Uprights
24x36 610x914 SCASCH-2436-4-SU 69 31 SCASCH-2436-4-AU 71 33
24x48 610x1219 SCASCH-2448-4-SU 78 35 SCASCH-2448-4-AU 80 37
24x60 610x1524 SCASCH-2460-4-SU 87 39 SCASCH-2460-4-AU 91 41
Solid Reinforced Shelving
Aluminum sheet with aluminum cross
tubes underneath for support. Ideal for
smaller merchandise. Shelf Capacity -
700 lb (318 kg)
Freight Class: 70
E Channel Shelving
4" x 1½" alu-
minum 14 gauge "E" Channel. Provides
increased surface area, yet allows for air
circulation. Channel is welded inside a
frame of tubing and flat bar. 18" & 21"
deep shelves have 2 channels, 24" deep
shelf has 3 channels. Shelf Capacity -
1,000 lb (454 kg)
Solid Reinforced Shelving Kits
Starter Kits & Add On Kits
Channel Shelving Kits
Freight Class: 70
