Pressure Gauge
Port (Optional)
Outlet 1/8” NPT
Increase to 1/2”
At this Point
Inlet 1/4” NPT
Decrease From
1/2” At this Point
Easy Flow
Bleed Valve
Inlet 1/2” NPT
Outlet 1/4” NPT
Increase to 1/2”
at this Point
Vacuum Gauge
Port
Easy Flow
Bleed Valve
Page 7
UPGRADE PUMP ASSEMBLY MODEL J
MAXIMUM PIPE LENGTH 90 FEET USING 1” PIPE
10 FOOT MAXIMUM LIFT
