SPECIFICATIONS
Control Interface 1 SPECIFICATIONS
Alarm Inputs
Assertion:
Transition from 0V to 1224V
Fault Inputs
Assertion:
Transition from +V to 0V
Maximum pullup resistor:
R7RST
Outputs
Assertion:
Low
Pullup Load:
D.F"RRST
Max. external supply:
35V
Max. continuous current:
350mA
Current Limit:
800mA
Power:
2 x 24V, 15Watts each
Dimensions
Height:
1.75 inches (44.45mm)
Width:
19 inches (483mm)
Depth:
10 inches (254mm)
Weight:
Approx 6.4lbs (2.8kg)
Ambient Operating Temperature:
32113°F (032°C)
Compliance:
FCC Part 15, class B
CE marked
KV"^N&'2";)(6,<)C"
RoHS Directive
UL 60065 Listed, E215636
CUL Listed, E215636
CTick, N24138 (Australia)
Control Interface 1 SPECIFICATIONS
Control Interface 1 BACK PANEL
Control Interface 1 BLOCK DIAGRAM
Alarm Inputs:
Assertion:
Transition from 0V to 12-24V
Fault Inputs:
Assertion:
Transition from +V to 0V
Maximum pull-up resistor:
2.2k
Outputs:
Assertion:
Low
Pull-up Load:
max 22k
Max. external supply:
35V
Max. continuous current:
350mA
Current Limit:
800mA
Power:
2 x 24V, 15Watts each
Dimensions:
Height:
1.75 inches (44.45mm)
Width:
19 inches (483mm)
Depth:
10 inches (254mm)
Weight:
Approx 6.4lbs (2.8kg)
Ambient Operating Temperature:
32-113°F (0-32°C)
Compliance:
FCC Part 15, class B
CE marked
EN 54-16 certified
RoHS Directive
UL 60065 Listed, E215636
C-UL Listed, E215636
C-Tick, N24138 (Australia)
8
7
6
5
4
3
2
1
1
2 Vref. 24V 100mA
10V
8
7
6
5
4
3
2
1
E
W
P
U
1
A
2
A
3
A
4
A
s
R
i
S
A
V
F
G
To LSI-16
System Fault
To LSI-16
24V Input
NO
C
C
N
To LSI-16 Control Inputs
To LSI-16 Monitored Outputs
CIE (Fire Detection System)
Fault Inputs
Power Supply
Assembled in USA
Designed in Australia
BIAMP SYSTEMS
Model CI-1
2 x 24V
15W Class 2 or LPS
N24138
10
52SJ
0832-CPD-1401
Silence
Test
Reset
Σ
Alarm/Fault Sounder
Switches
24VDC
1
2
To LSI-1
6
Power
In
CIE
Fault Inputs
