3
REMOtE EthERNEt DEvIcE 1 (RED-1)
RED-1 Remote Ethernet Device is a remote control for Audia ® and Nexia ® systems. It offers a simple, intuitive interface for end users and
can be installed and configured to fit the unique needs of a particular application. The device connects via standard Ethernet cabling and is
powered over Ethernet, eliminating the need for custom cabling and local power sources. Multiple remote control panels can be connected
over large distances using standard network technology.
Features
Adjustment and/or initiation of up to 32 selectable system volumes and actions •
Volumes are any individual or grouped system levels, including inputs, outputs, matrix cross-points, etc. •
Actions are any individual or grouped system operations, including presets, source selection, mutes, ducking, combining, etc. •
Control functions are programmed in the Audia and Nexia system design software •
High contrast OLED (Organic Light-Emitting Diode) display with a wide viewing angle •
The display brightness can be adjusted to fit the ambient light present in the application and can automatically dim when not in use •
Capacitive touch technology eliminates protruding and moving parts to increase product reliability and longevity while •
simplifying cleaning
RED-1 surface mounts or flush mounts to most walls with a wide variety of mounting holes to accommodate standard US and
•
international back boxes. RED-1F flush-mounts to any wall; mounts using the retrofit plate (included) or installs in a Raco ® 254
box for North American installation (not included).
330' (100m) Ethernet cable length can be extended with standard PoE network technology (routers, switches, hubs,
•
media converters)
Connects with standard RJ45 or insulation displacement connector (IDC)
•
Covered by • Biamp Systems’ five-year warranty
RED-1F RED-1
