Advanced parameters and commands
Pearleye Technical Manual V2.3.0
59
Pearleye P-007 LWIR
...wait for at least 36 image cycles (34 + 2 frames jitter buffer, 0.9 seconds at 40
images / sec.) or poll the state of bit group
d with H[CR]...
Pearleye P-030 LWIR
...wait for at least 36 image cycles (34 + 2 frames jitter buffer, 1.50 seconds at
24 images / sec.) or poll the state of bit group
d with H[CR]...
>
H=0[CR]
Baud rate (s)
The baud rate of the RS232 interface is determined by use of register
s:
The bits of the parameter value are divided into three different sized bit groups
a, e and x. Each bit group has a special function, being independent of the other
ones:
•
a: Controls the configuration of the serial port.
•
e: Controls the echo mode.
•
x: Controls the baud rate of the serial port.
GigE Vision feature name
Description
IIS_OperationMode
Operation mode of the integrator and image store.
(H=
While reading this feature the MSB shows the state of the
integration process.
(0=Idle, 1=Busy)
Table 30: Camera special feature: IntegratorAndImageStore
Note
This function is not available as GigE Vision feature.
Caution
Do not change the baud rate, if the camera is to be controlled
via GigE Vision features.
