Pressure – Temperature Chart, R-410A & R-22
PSIG PSIG PSIG PSIG PSIG PSIG PSIG
(
°F) R-410A R-22 (°F) R-410A R-22 (°F) R-410A
R-22
(
°F) R-410A
R-22
(
°F) R-410A
R-22
(
°F) R-410A R-22 (°F) R-410A
R-22
-40
10.8 0.6 -10
36.4 16.5 20
78.3 43.1 50
142.2 84.1 80
234.9 143.6 110 364.1 226.4 140
540.1 337.4
-39
11.5 1.0 -9
37.5 17.2 21
80.0 44.2 51
144.8 85.7 81
238.6 146.0 111 369.1 229.6 141
547.0 341.6
-38
12.1 1.4 -8
38.6 17.9 22
81.8 45.3 52
147.4 87.4 82
242.3 148.4 112 374.2 232.8 142
553.9 345.9
-37
12.8 1.8 -7
39.8 18.7 23
83.6 46.5 53
150.1 89.1 83
246.0 150.8 113 379.4 236.1 143
560.9 350.3
-36
13.5 2.2 -6
40.9 19.4 24
85.4 47.6 54
152.8 90.8 84
249.8 153.2 114 384.6 239.4 144
567.9 354.6
-35
14.2 2.6 -5
42.1 20.1 25
87.2 48.8 55
155.5 92.6 85
253.7 155.7 115 389.9 242.8 145
575.1 359.0
-34
14.9 3.1 -4
43.3 20.9 26
89.1 50.0 56
158.2 94.4 86
257.5 158.2 116 395.2 246.1 146
582.3 363.5
-33
15.6 3.5 -3
44.5 21.7 27
91.0 51.2 57
161.0 96.1 87
261.4 160.7 117 400.5 249.5 147
589.6 368.0
-32
16.3 4.0 -2
45.7 22.4 28
92.9 52.4 58
163.8 98.0 88
265.4 163.2 118 405.9 253.0 148
596.9 372.5
-31
17.1 4.5 -1
47.0 23.2 29
94.9 53.7 59
166.7 99.8 89
269.4 165.8 119 411.4 256.5 149
604.4 377.1
-30
17.8 4.9 0
48.3 24.0 30
96.8 55.0 60
169.6 101.6 90
273.5 168.4 120 416.9 260.0 150
611.9 381.7
-29
18.6 5.4 1
49.6 24.9 31
98.8 56.2 61
172.5 103.5 91
277.6 171.0 121 422.5 263.5
-28
19.4 5.9 2
50.9 25.7 32
100.9 57.5 62
175.4 105.4 92
281.7 173.7 122 428.2 267.1
-27
20.2 6.4 3
52.2 26.5 33
102.9 58.8 63
178.4 107.3 93
285.9 176.4 123 433.9 270.7
-26
21.1 6.9 4
53.6 27.4 34
105.0 60.2 64
181.5 109.3 94
290.1 179.1 124 439.6 274.3
-25
21.9 7.4 5
55.0 28.3 35
107.1 61.5 65
184.5 111.2 95
294.4 181.8 125 445.4 278.0
-24
22.7 8.0 6
56.3 29.2 36
109.2 62.9 66
187.6 113.2 96
298.7 184.6 126 451.3 281.7
-23
23.6 8.5 7
57.8 30.1 37
111.4 64.3 67
190.7 115.3 97
303.0 187.4 127 457.3 285.4
-22
24.5 9.1 8
59.2 31.0 38
113.6 65.7 68
193.9 117.3 98
307.5 190.2 128 463.2 289.2
-21
25.4 9.6 9
60.7 31.9 39
115.8 67.1 69
197.1 119.4 99
311.9 193.0 129 469.3 293.0
-20
26.3 10.2 10
62.2 32.8 40
118.1 68.6 70
200.4 121.4 100
316.4 195.9 130 475.4 296.9
-19
27.2 10.8 11
63.7 33.8 41
120.3 70.0 71
203.6 123.5 101
321.0 198.8 131 481.6 300.8
-18
28.2 11.4 12
65.2 34.8 42
122.7 71.5 72
207.0 125.7 102
325.6 201.8 132 487.8 304.7
-17
29.2 12.0 13
66.8 35.8 43
125.0 73.0 73
210.3 127.8 103
330.2 204.7 133 494.1 308.7
-16
30.1 12.6 14
68.3 36.8 44
127.4 74.5 74
213.7 130.0 104
334.9 207.7 134 500.5 312.6
-15
31.1 13.2 15
69.9 37.8 45
129.8 76.1 75
217.1 132.2 105
339.6 210.8 135 506.9 316.7
-14
32.2 13.9 16
71.5 38.8 46
132.2 77.6 76
220.6 134.5 106
344.4 213.8 136 513.4 320.7
-13
33.2 14.5 17
73.2 39.9 47
134.7 79.2 77
224.1 136.7 107
349.3 216.9 137 520.0 324.8
-12
34.2 15.2 18
74.9 40.9 48
137.2 80.8 78
227.7 139.0 108
354.2 220.0 138 526.6 329.0
-11
35.3 15.9 19
76.6 42.0 49
139.7 82.4 79
231.3 141.3 109
359.1 223.2 139 533.3 333.2
