Air Squared V12H20N2.5 - Manual

US World
Max. Pressure < 15 torr <20 mbar
Max. Flow 0.9 cfm 25 lpm
Rated Power 0.10 hp 75 W
Motor Type Brushless DC
Voltage 12V - 24V DC
Avg. Sound Level 35 dB(A)
Net Weight 3 lb 1.36 kg
Port Configuration 1/8” NPT
Ambient Temp. 0°F - 104°F -20°C - 40°C
Model Number V12H20N2.5
Air Squared
Manufacturing, Inc.
- 100% Oil-Free
- Low Sound Levels
- Balanced, Smooth, Rotary Motion
- High Efficiency
- Long Product Life
- Continuous Duty
- Small Compact Design
- Lightweight
- Minimal Pulsation
- Field Serviceable
Technical Overview
V12H20N2.5
40 Years of Scroll Technology
Product Features
- DC Controller Available For Purchase
- Cooling Fan
Optional Configurations
Qualified OEM designers should consult Air Squared Manufacturing, Inc. for custom
configurations and application specific requirements. Contact [email protected].
The information presented in this material is based on technical data and test results of nominal
units. It is believed to be accurate and reliable. Air Squared, Inc. does not warrant, guarantee, or
assume liability in connection with this information.
Application conditions may adversely affect performance and product life. It is the responsibility
of the user to determine the suitability of the product for intended use.
Scroll Vacuum Pump
