Air Squared P22H38N42.5 - Manual

US World
Max. Pressure 80 psig 5.5 barg
Max. Flow 15 cfm 425 lpm
Rated Power 4.5 hp 3.4 kW
Motor Type AC
Voltage 230/460V AC
Avg. Sound Level 50 dB(A)
Port Configuration
SAE 1.312-12 (Inlet)
SAE .75-16 (Discharge)
Model Number P22H38N4.25
Scroll Compressor
Air Squared
Manufacturing, Inc.
- Semi-hermetic For Gases Other Than Air
- Integrated Cooling Fan
- 100% Oil-free or Lubricated
- Low Sound Levels
- Balanced, Smooth, Rotary Motion
- High Efficiency
- Long Product Life
- Continuous Duty
- Minimal Pulsation
Technical Overview
P22H38N42.5
40 Years of Scroll Technology
Product Features
Qualified OEM designers should consult Air Squared Manufacturing, Inc. for custom
configurations and application specific requirements. Contact [email protected].
The information presented in this material is based on technical data and test results of nominal
units. It is believed to be accurate and reliable. Air Squared, Inc. does not warrant, guarantee, or
assume liability in connection with this information.
Application conditions may adversely affect performance and product life. It is the responsibility
of the user to determine the suitability of the product for intended use.
