Air Squared V13H24N4.0 User Manual
Scroll vacuum pump, 40 years of scroll technology, Air squared

US
Europe
Max. Vacuum
> 29 in Hg
< 20 mbar
Max. Flow
4.6 cfm
130 lpm
Rated Power
0.75 hp
1000 W
Motor Type
BLDC (AC Optional)
Voltage
24V-48V DC
Avg. Sound Level
45 dB(A)
Net Weight
4 lb
1.8 kg
Max. Amb. Temp.
104°F
40°C
Model Number
V13H24N4.0
Part Number
Scroll Vacuum Pump
Air Squared
Manufacturing, Inc.
-
100% Oil-Free
-
Low Sound Levels
-
Balanced, Smooth, Rotary Motion
-
High Efficiency
-
Long Product Life
-
Continuous Duty
-
Small Compact Design
-
Lightweight
-
Minimal Pulsation
- Field Serviceable
Product Features
Technical Overview
Contact [email protected] for custom design information
or application specific requirements.
V13H24N4.0
40 Years of Scroll Technology
