Air Squared P22H40N2.5 - Manual

US World
Max. Pressure 25 psig 1.72 barg
Max. Flow 14 cfm 400 lpm
Rated Power 1.34 hp 1 kW
Motor Type Brushless DC
Voltage 36V - 48V DC
Avg. Sound Level 50 dB(A)
Net Weight 24 lb 11 kg
Port Configuration 3/4” NPT
Ambient Temp. 0°F - 104°F -20°C - 40°C
Model Number P22H40N2.5
Scroll Compressor
Air Squared
Manufacturing, Inc.
- 100% Oil-Free
- Balanced, Smooth, Rotary Motion
- High Efficiency
- Long Product Life
- Continuous Duty
- Small Compact Design
- Minimal Pulsation
- Field Serviceable
Technical Overview
P22H40N2.5
40 Years of Scroll Technology
Product Features
- DC Controller Available For Purchase
Optional Configurations
Qualified OEM designers should consult Air Squared Manufacturing, Inc. for custom
configurations and application specific requirements. Contact [email protected].
The information presented in this material is based on technical data and test results of nominal
units. It is believed to be accurate and reliable. Air Squared, Inc. does not warrant, guarantee, or
assume liability in connection with this information.
Application conditions may adversely affect performance and product life. It is the responsibility
of the user to determine the suitability of the product for intended use.
