Air Squared P13H24N4.0 User Manual
Scroll compressor, 40 years of scroll technology, Air squared

US
Europe
Max. Pressure
80 psig
5.52 barg
Max. Flow
4.6 cfm
130 lpm
Rated Power
0.75 hp
1000 W
Motor Type
BLDC (AC Optional)
Voltage
24V-48V DC
Avg. Sound Level
45 dB(A)
Net Weight
18 lb
8.2 kg
Max. Amb. Temp.
104°F
40°C
Model Number
P13H24N4.0
Part Number
081020
Scroll Compressor
Air Squared
Manufacturing, Inc.
-
100% Oil-Free
-
Low Sound Levels
-
Balanced, Smooth, Rotary Motion
-
High Efficiency
-
Long Product Life
-
Continuous Duty
-
Small Compact Design
-
Lightweight
-
Minimal Pulsation
- Field Serviceable
Product Features
Technical Overview
Contact [email protected] for custom design information
or application specific requirements.
P13H24N4.0
40 Years of Scroll Technology
