6. SPECIFICATIONS
DDK-1700D
Image sensor 1/2.7 ” 2M CMOS sensor
Lens 2.9~8.2mm C/CS MOUNT/3.3~12mm vari-focal board type
Minimum illumination
Color: 0.2 Lux @ F1.4.;
B/W: 0.02 [email protected]
IR cut filer Yes
Day & Night Auto / Day / Night / Schedule.
Video Compression H.264 / MPEG4 / MJPEG.
Resolution
-1080P (1920 x 1080), 720P (1280x720),
-VGA (640x480), QVGA (320x240), QQVGA (160x120)
Video streaming
- Simultaneous H.264, MPEG4 and MJPEG.
- Multi-profile: resolution / compression / frame rate / video
quality.
Profiles 3
Frame rate
Single profile (1920x1080): 30FPS
Multi-profile (1920x1080): 20FPS
Image settings
- Adjustable image size, quality, and bit rate.
- Day / Night mode.
- Flip & Mirror.
- AGC, AWB, AES.
- Time stamp and text caption overlay.
- Privacy masks.
Video management
software
SDK, including HTTP-API / ActiveX / ONVIF.
Audio
Audio streaming Two-way.
Compression G.711u / G.726.
Audio bit rate G.711u 64kbps / G.726 32kbps.
Inputs / outputs: 1 x input / 1 x output (3.5mm earphone jack).
Network
Security
Multi-level password protections, IP address filtering, HTTPS
encryption, User access log.
Protocols
IPv4, HTTPS, HTTP, TCP, UDP, RTP/RTCP/RTSP, DHCP, NTP,
FTP, SMTP, UPnP, ICMP, ARP, DDNS, PPPoE, SAMBA
Users Access by 8 simultaneous users.
Firmware update SD card / HTTP.
Alarm
Recording SD card, SAMBA, FTP
Pre-alarm recording Yes.
Advanced motion 512 zones. Sensitivity: 0 - 100 %.
Trigger
Motion Detection
Schedule
Alarm input
Ethernet loss
Network/Remote digital alarm input
Notification SD card recording, SMTP, FTP, HTTP, alarm output.
