IPX DDK-1800 User Manual
Page 83
Size
Stretch:
Click “Stretch” and the image will be stretched to fit the
entire viewable area.
Force Turn On:
Click “Force Turn On” and the image will be shown
in the DDK-1800D’s original image ratio centered in the display area.
Auto:
Click “Auto” and the image will be stretched to fit the entire
viewable area of the viewer in DDK-1800Ds normal ratio.
Full Screen:
Click “Full Screen” and the image will be stretched to
the displays full screen area.
Add a DDK-1800D to Live View area:
1.
Click the DDK-1800D.
2.
Hold down the right mouse button and drag onto the Live View area. The video from the
DDK-1800D will be displayed.
3.
To change/remove DDK-1800Ds or use the "Audio On/Off" or "Snapshot" functions,
right click again on the live view area, then click left to select.
Remove a DDK-1800D from the Live View area:
1.
Select the DDK-1800D to be deleted.
2.
Right click on the live view area, then click left to select “Delete”.
83
