TABLE1
XG PARAMETER CHANGE TABLE ( UNIQUE EFFECT)
Address
Size
Data
Parameter
Description
Default
(H)
(H)
(H)
04
n
00
2
00 - 7F
UNIQUE INSERTION EFFECT TYPE MSB
Refer to XG EFFECT MAP
59(=Vocoder harmony)
00 - 7F
UNIQUE INSERTION EFFECT TYPE LSB
00 : basic type
00
02
1
00 - 7F
UNIQUE INSERTION EFFECT PARAMETER1
Refer to Effect parameter list
depends on type
03
1
00 - 7F
UNIQUE INSERTION EFFECT PARAMETER2
Refer to Effect parameter list
depends on type
04
1
00 - 7F
UNIQUE INSERTION EFFECT PARAMETER3
Refer to Effect parameter list
depends on type
05
1
00 - 7F
UNIQUE INSERTION EFFECT PARAMETER4
Refer to Effect parameter list
depends on type
06
1
00 - 7F
UNIQUE INSERTION EFFECT PARAMETER5
Refer to Effect parameter list
depends on type
07
1
00 - 7F
UNIQUE INSERTION EFFECT PARAMETER6
Refer to Effect parameter list
depends on type
08
1
00 - 7F
UNIQUE INSERTION EFFECT PARAMETER7
Refer to Effect parameter list
depends on type
09
1
00 - 7F
UNIQUE INSERTION EFFECT PARAMETER8
Refer to Effect parameter list
depends on type
0A
1
00 - 7F
UNIQUE INSERTION EFFECT PARAMETER9
Refer to Effect parameter list
depends on type
0B
1
00 - 7F
UNIQUE INSERTION EFFECT PARAMETER10
Refer to Effect parameter list
depends on type
0C
1
00 - 7F
UNIQUE INSERTION EFFECT PART
Part1...64(0...63)
7F
AD1...AD63(64...126)
OFF(127)
0D
1
00 - 7F
MW UNIQUE INSERTION CONTROL DEPTH
-64 - 63
40
0E
1
00 - 7F
BEND UNIQUE INSERTION CONTROL DEPTH
-64 - 63
40
0F
1
00 - 7F
CAT UNIQUE INSERTION CONTROL DEPTH
-64 - 63
40
10
1
00 - 7F
AC1 UNIQUE INSERTION CONTROL DEPTH
-64 - 63
40
11
1
00 - 7F
AC2 UNIQUE INSERTION CONTROL DEPTH
-64 - 63
40
TOTAL SIZE
12
04
n
14
1
00 - 7F
UNIQUE INSERTION EFFECT EXTERNAL
1...16(0...15), off(127)
7F
CONTROL CH1(HARMONY CHANNEL)
15
1
00 - 7F
UNIQUE INSERTION EFFECT EXTERNAL
1...16(0...15), off(127)
7F
CONTROL CH2 (MELODY CHANNEL)
TOTAL SIZE
2
04
n
20
1
00 - 7F
UNIQUE INSERTION EFFECT PARAMETER11
Refer to Effect parameter list
depends on type
21
1
00 - 7F
UNIQUE INSERTION EFFECT PARAMETER12
Refer to Effect parameter list
depends on type
22
1
00 - 7F
UNIQUE INSERTION EFFECT PARAMETER13
Refer to Effect parameter list
depends on type
23
1
00 - 7F
UNIQUE INSERTION EFFECT PARAMETER14
Refer to Effect parameter list
depends on type
24
1
00 - 7F
UNIQUE INSERTION EFFECT PARAMETER15
Refer to Effect parameter list
depends on type
25
1
00 - 7F
UNIQUE INSERTION EFFECT PARAMETER16
Refer to Effect parameter list
depends on type
TOTAL SIZE
6
n : refers to a number used to recognize individual boards when multiple boards are installed.
n=0: board 1
n=1: board 2
INSERTION EFFECT TYPE MSB
: h’ 59=Vocoder harmony
: h’ 5A=Chordal harmony
: h’ 5B=Detune harmony
: h’ 5C=Chromatic harmony
For all other values, “Thru” will be selected and the input signal will be output as is.
MW INSERTION CONTROL DEPTH
: Not supported by this board
BEND INSERTION CONTROL DEPTH
: Not supported by this board
CAT INSERTION CONTROL DEPTH
: Not supported by this board
AC1 INSERTION CONTROL DEPTH
: Not supported by this board
AC2 INSERTION CONTROL DEPTH
: Not supported by this board
HARMONY CHANNEL
: Controls the harmony
MELODY CHANNEL
: Controls the melody as well as the gender setting for the harmony
TABLE2
XG PARAMETER CHANGE TABLE ( SYSTEM )
Address
Size
Data
Parameter
Description
Default
(H)
(H)
(H)
0
0
0
4
0000 - 07FF MASTER TUNE
-102.4 - +102.3[cent]
00 04 00 00
1
1st bit3-0mbit15-12
2
2nd bit3-0mbit11-8
3
3rd bit3-0mbit7-4
4th bit3-0mbit3-0
4
1
00 - 7F
MASTER VOLUME
0 - 127
7F
5
1
00 - 7F
MASTER ATTENUATOR
0 - 127
0
6
1
28 - 58
TRANSPOSE
-24 - +24 [semitones]
40
TOTAL SIZE
7
MASTER VOLUME and MASTER ATTENUATOR are not supported by this board.
They can be controlled through the plug-in platform.
