Appendix
02 18
mm
Harmony 3 Volume
O
X
mm : 00 - 127 (0...127)
The following NRPN numbers independently control the panning of each harmony note.
The currently-sounding harmony notes are numbered sequentially beginning from the lowest note.
When the value is 0, panning will be random.
For random panning with Vocoder harmony, the pan position will change at each key-on.
For random panning with Chordal harmony, the pan position will change whenever the chord changes.
For Detune and Chromatic harmony, random pan will not function, and the panning will be centered.
02 32
mm
Harmony 1 Pan
O
X
mm : 00, 01 - 64 - 127 (random, Lch...center...Rch)
02 33
mm
Harmony 2 Pan
O
X
mm : 00, 01 - 64 - 127 (random, Lch...center...Rch)
02 34
mm
Harmony 3 Pan
O
X
mm : 00, 01 - 64 - 127 (random, Lch...center...Rch)
The following NRPN numbers independently control the detune amount for each harmony sound.
The currently-sounding harmony notes are numbered sequentially beginning from the lowest note.
02 48
mm
Harmony 1 Detune
O
X
mm : 00 - 64 - 127 (-64...0...+63)
02 49
mm
Harmony 2 Detune
O
X
mm : 00 - 64 - 127 (-64...0...+63)
02 50
mm
Harmony 3 Detune
O
X
mm : 00 - 64 - 127 (-64...0...+63)
1.2.4 RPN (Registered Parameter Number)
This message is used to set Pitch Bend Sensitivity.
RPN MSB and RPN LSB are used to specify the parameter which is to be controlled, and subsequently
Data Entry (refer to 1.2.1) is used to set the value of the specified parameter.
Only the MSB of Data Entry is recognized.
Control#
Parameter
Data Range
100
RPN LSB
0...127
101
RPN MSB
0...127
The following RPN numbers are recognized.
RPN
Data Entry
Parameter name and range of values
Harmony ch
Melody ch
MSB LSB
MSB
00H 00H
mm
Pitch Bend Sensitivity
O
O
mm : 00 - 24 (0...24 semitones)
Settable in semitone steps over a two-octave range
7FH 7FH
—
RPN null
O
O
Set RPN and NRPN numbers to a condition in which no numbers have been specified.
Internal settings will not be affected.
1.2.5 All Note Off
For Vocoder harmony, this message turns off all currently-sounding harmony notes.
Control#
Parameter
Data Range
123
All Note Off
0
1.3 Pitch Bend
Harmony ch
Melody ch
En
vv
vv
O
O
n
:
MIDI channel
vv
:
data
This message conveys operations of the pitch bender.
It will modify the pitch in the range specified by RPN Pitch Ben Sensitivity.
For the Melody channel, this message will have an effect only when Lead Gender is ON.
2. System exclusive messages
2.1 GM system on
F0
7E
7F
09
01
F7
F0
7E
0n
09
01
F7
This message initializes the tone generator system.
All default values are restored.
n
:
device number
2.2 XG system on
F0
43
1n
4C
00
00
7E
00
F7
This message initializes the tone generator system.
All default values are restored.
n
:
device number
2.3 XG parameter change format
F0
43
1n
4C
aa
aa
aa
dd
F7
This message sends and receives parameters from tables 1 and 2 as a single message unit (combines and sends/receives 2 byte parameters).
n
:
device number
aa
:
address
dd
:
data
