Valco electronic Valve Oven - Manual (Page 30)

Chapter 2
Valve Installation
Installing Valves in the Unheated Compartment
30 Operating Manual
Figure 2-6. Installing an Unheated Compartment Valve
1. Valve 2. Valve Mechanical Stop
3. Collar “A” 4. Actuator
2
3
4
1
