TP-6804 12/11 48 Section 3 RDC2 Controller Operation
3.19 Programmable Interface
Module (PIM) Status Menu
The PIM status menu displays the status of inputs and
outputs connected to the programmable interface
module (PIM). This is a status display menu only. Input
and output settings cannot be changed from the RDC2
controller’s user interface.
A personal computer running Kohler
r SiteTecht
software is required to change the input and output
settings. Contact an authorized distributor or dealer for
service.
The Kohler
r OnCuet Home Management System can
be used to turn outputs on and off. See the OnCue
Software Operation Manual for instructions.
tp6810
PIM
Status: PIM 1 ---->
<---- Return
Input 1
In/Active
Output 1:
In/Active
Input 2
In/Active
Output 2:
In/Active
Output 3:
In/Active
Output 4:
In/Active
Output 5:
In/Active
Output 6:
In/Active
<---- Return
Figure 3-24 Programmable Interface Module (PIM) Status Menu
