TP-6804 12/11 31 Section 3 RDC2 Controller Operation
3.2.3 LCD Display
The controller is equipped with a two-line x 16 character
backlit digital display with adjustable contrast. When the
generator is running, the controller automatically scrolls
through the displays shown in Figure 3-5. When the
system is in AUTO, the screens shown in Figure 3-6 are
displayed.
When a fault or warning condition exists, the controller
will show the corresponding message. See Section 2.5
for more information about faults.
Controller menus display power system information,
including status information for the engine, generator,
and optional RBUS accessories, exercise settings, and
event history.
Some menus allow changes to the
controller settings. See Sections 3.7 through 3.21 for
menu diagrams.
tp6804
Genset Status
Running
Voltage: 240V
Freq:
60.0Hz
Engine: 123F
Oil Pressure: OK
Battery
12.3V
Engine Runtime:
12345.6 h
Date: 02DEC2011
Time: HR:MNpm
Active Alert
Sample data shown.
Figure 3-5 Autopaging Displays, Generator Running
The display contrast is adjustable. Navigate to the
Genset System menu and step down to the Contrast
screen. Press the Select button, and then use the up
and down arrow buttons to adjust the contrast. See
Section 3.5, Changing Settings, and Section 3.14,
Genset System Menu.
The display backlight turns off after about a minute of no
activity. The backlight turns on when a button is pressed
or when the generator set starts.
tp6804
Battery
12.3V
Engine Runtime:
12345.6 h
Date: 02DEC2011
Time: HR:MNpm
Next Exercise:
09:00p 09Dec2011
Next Maintenance:
150 h or Mar2012
Sample data shown.
Genset Status
Standby
Active Alert
Figure 3-6 Autopaging Displays, Automatic Mode
