Kohler Power Systems 14/20RESA - Manual (Page 25)

TP-6804 12/11 25 Section 2 Generator Set Operation
2.5.4 Resetting the Controller after a
Fault Shutdown
Always identify and correct the cause of a fault
shutdown before resetting the controller. Check the
fault message displayed on the controller and refer to
Figure 2-3 to identify and correct the fault condition
before
proceeding. Contact an authorized
distributor/dealer for service, if necessary.
RDC2 Controller
Press the OFF button to reset the controller, or follow the
procedure below. See Figure 2-2.
1. While the fault message is displayed, press the
Select button to go to the Overview menu.
2. Press Select again. The active fault message is
displayed.
3. Press Select. Confirm Clear Fault: NO is
displayed.
4. Press the Down arrow button. Confirm Clear Fault:
YES is displayed.
5. Press the Select button to enter YES and clear the
fault.
6. Press the Select button to return to the overview
menu. The controller changes to OFF mode.
7. Press AUTO to put the generator set into automatic
mode.
DC2 Controller
Press the OFF button to clear the fault message on the
controller.
Overview ---->
1.2 h Fault Message
tp6809
Confirm Clear
Fault: NO
Confirm Clear
Fault: YES
Fault Message
Press Up arrow button.
Figure 2-2 Clearing a Fault on the RDC2 Controller
