6.4
Supply module for BCS 302
ex
Terminal connection diagram for hand-held scanner BCS 302
ex
to supply module via a connector/adapter.
Panel PC
Terminal no.
Description Adapter / connector
PIN
Description BCS
302
ex
PIN
Description
2
1
3
TxD
+U
B
GND
PIN 3
PIN 1
PIN 2
TxD / RxD
Ucc / +U
B
GND
PIN 3
PIN 1
PIN 2
TxD / RxD
Ucc
GND
