Invacare A-TTM - Manual (Page 81)

Stroller Handles - 1483
Item
Number Part Number Description Note
Quantity Per
Package Assembly
1014386 Screw, Phillips Pan Head (#8-32 x 5/8") 1 2 1
1045470 Pin, Quick Release with Lanyard 1 2 2
1016254 Grip, Push Handle 1 4 3 E
1055228 Handle, Stroller, Black - Left 1 1 4 A
1045552-NLA NLA - Handle, Stroller, Black - Left 1 1 4 B
1055230-NLA NLA - Handle, Stroller, Chrome - Left 1 1 4 A
1049512 Handle, Stroller, Chrome - Left 1 1 4 B
1055226 Slide Tube w/ Snap Buttons Assembly, Chrome 1 1 5 A
1045361 Slide Tube w/ Snap Buttons Assembly, Short,
Chrome 1 1 5 C
1045360-NLA NLA - Slide Tube w/ Snap Buttons Assembly, Long,
Chrome 1 1 5 D
See Chart #6 Spacer Tube 1 1 6
1055227 Handle, Stroller, Black - Right 1 1 7 A
1045551-NLA NLA - Handle, Stroller, Black - Right 1 1 7 B
1055229-NLA NLA - Handle, Stroller, Chrome - Right 1 1 7 A
1049511 Handle, Stroller, Chrome - Right 1 1 7 B
40188X009 Button, Single Snap 1 2 8
See Chart #9 Stroller Handle Assembly - Black 1 1 9
See Chart #9 Stroller Handle Assembly - Chrome 1 1 9
A - 14-15" Wide Chairs
B - 16-22" Wide Chairs
C - 16-20" Wide Chairs
D - 21-22" Wide Chairs
E - 14-17" wide chairs require 3 ea.; 18-22" wide chairs require 4 ea. NOTE:
#6 Spacer Tube
14"
Wide
15"
Wide
16"
Wide
17"
Wide
18"
Wide
1046178 1049513 Not Required 1049516 1049515
22"
Wide
21"
Wide
20"
Wide
19"
Wide
1049517-NLA 1049516 1049515 1049514
80
To order call toll free 1-800-333-6900, or www.invacare.com
Form No. 94-143
