Invacare A-TTM - Manual (Page 51)

Vent Tray
Item
Number Part Number Description Note
Quantity Per
Package Assembly
1008432 Screw, Socket Button Head (1/4-20 x 1-1/4") 1 4 1
7930323 Package, Locknut (1/4-20) 25 4 2
40157X020 Spacer, Coved (1/4 x 1 x 9/16") 1 2 3
1028478 Screw, Hex Head (5/16-18 x 1-1/4") 1 2 4
1028769 Locknut (5/16-18) 1 2 5
15680X012 Collar, Anti-Rattle (7/8") 1 2 6
1052427 Vent Tray w/ Straps 1 1 7 A
1052426 Buckle, Slide Release 1 1 8
1052424 Strap with Slide Release Buckle (22" Long) 1 1 9
8881052421 Tube, Insert, Color 1 1 10 B
1052422-NLA NLA - Insert Tube, Chrome 1 1 10 C
8881052417 Tube, Extension, Color - Right 1 1 11 B
8881052418 Tube, Extension, Color - Left 1 1 11 B
1052419 Tube, Extension, Chrome - Right 1 1 11
1052420 Tube, Extension, Chrome - Left 1 1 11
1097003 Battery Box Top, Rear, 22NF 1 1 12 D
1057944 Battery Box Bottom with Strap, 22NF 1 1 13
A - Vent Tray Option can only be used on Base Frames without rear cross tube.
B - Specify Frame color when ordering.
C - If chrome Insert Tube is requested it must be ordered as "special". Use part number 1052421 when ordering.
D - 16-20" Wide NOTE:
50
To order call toll free 1-800-333-6900, or www.invacare.com
Form No. 94-143
