Casters and Forks
Item
Number Part Number Description Note
Quantity Per
Package Assembly
1037420 Fork and Stem Assembly, Black (6 x 1" Caster) 1 1 1 A
1050138 Fork and Stem Assembly 1 1 1 B
1001843 Cap, Head Tube, Black 1 1 2
1131189 Package, Head Tube Cap 10 1 2
1001979 Locknut (1/2-20) 1 1 3
1021508 Washer, Nylon (5/8 x 1 x 3/32") 1 1 4
See Chart #'s 5-9 Caster Wheels 1 1 5-9
See Chart #'s 10-12 Caster Hardware 1 1 10-12
A - AT902 (6 x 1") casters
B - 1259 (6 x 2") and all 8" casters NOTE:
Caster Wheels
Wheel Style 8. Tire
9. Tube/
Insert
Wheel Size Tire Type 5. Bearing
6. Bearing
Spacer
7. Wheel w/
Bearing
N/A N/A
1034352
N/A N/A Urethane 6 x 1" AT902
See Note(s) C
N/A N/A
1122066
1020592 1006049
Semi
Pneumatic
6 x 2"
Deep Profile
1259
(Before
8/15/03)
See Note(s) B, A See Note(s) B, C
N/A N/A 1115179 1020592 1006049
Semi
Pneumatic
6 x 2"
Deep Profile
1259
(After
8/14/03)
See Note(s) A
N/A 1040144 1058137 1018982 1006049 Solid Rubber 8 x 1" 1299
N/A N/A 1070811 1020592 1006049
Semi-
Pneumatic
8 x 2" 1228
40176X041 40176X040 1009481 1020592 1006049 Pneumatic 8 x 1-1/4" 1292
1010904 40176X040 1030773 1020592 1006049
Pneumatic
w/ Flat Free
8 x 1-1/4" 1492
A - 1259 casters use 8" caster fork and stem.
B - Due to product improvement, previous caster is NLA. Order (pair) part number 1122066 so casters will match. The deep profile
caster has 2 tread grooves w/ round corners instead of 4 tread grooves w/ square corners.
C - Consists of (2) Casters. NOTE:
Caster Hardware
Wheel Style Wheel Size Tire Type 10. Axle 11. Locknut 12. Spacer
1026102 1025730 1025764 Urethane 6 x 1" AT902
1026102 1025730 1025764
Semi-
Pneumatic
6 x 2" 1259
1026101 1025734 1025726 Solid Rubber 8 x 1" 1299
37
