Footrest Support Assemblies
(Swingaway 60 Degree, 70 Degree, and 90 Degree)
Item
Number Part Number Description Note
Quantity Per
Package Assembly
1001762 Screw, Socket Button Head (1/4-20 x 1-3/4") 1 1 1
1029501 Plug Button, Black (1") 1 1 2
1056328 Plug Button, Black (1") 1 1 2
1017148 Pivot, Footrest 1 1 3
1025736 Locknut (1/4-20) 1 1 4
1025451 Screw, Slotted Hex Washer Head (#10-32 x 5/8") 1 2 5
1017423 Screw, Slotted Hex Washer Head w/ Patch (#10-32
x 1/2") 1 1 6
1025454 Housing, Latch - Right 1 1 7
1025455 Housing, Latch - Left 1 1 7
1026124 Collar, Anti-Rattle 1 1 8
8881026992 Footrest Support Assembly, 60 Degree, Sector,
Color - Right 1 1 9 A,D
8881026993 Footrest Support Assembly, 60 Degree, Sector,
Color - Left 1 1 9 A,D
8881026998 Footrest Support Assembly, 60 Degree MFX,
Sector, Color - Right 1 1 9 A,D
8881026999 Footrest Support Assembly, 60 Degree MFX,
Sector, Color - Left 1 1 9 A,D
8881053158 Footrest Support Assembly, 60 Degree Heavy Duty,
Sector, Color - Right 1 1 9 A,B,C
8881053157 Footrest Support Assembly, 60 Degree Heavy Duty,
Sector, Color - Left 1 1 9 A,B,C
8881026994 Footrest Support Assembly, 70 Degree
Non-Tapered, Sector, Color - Right 1 1 9 A,D
8881026995 Footrest Support Assembly, 70 Degree
Non-Tapered, Sector, Color - Left 1 1 9 A,D
8881026996 Footrest Support Assembly, 70 Degree Tapered,
Sector, Color - Right 1 1 9 A,D
8881026997 Footrest Support Assembly, 70 Degree° Tapered,
Sector, Color - Left 1 1 9 A,D
8881047481 Footrest Support Assembly, 70 Degree MFX,
Sector, Color - Right 1 1 9 A,D
8881047480 Footrest Support Assembly, 70 Degree MFX,
Sector, Color - Left 1 1 9 A,D
8881053149 Footrest Support Assembly, 70 Degree
Non-Tapered Heavy Duty, Sector, Color - Right 1 1 9 A,B,C
8881053148 Footrest Support Assembly, 70 Degree
Non-Tapered Heavy Duty, Sector, Color - Left 1 1 9 A,B,C
8881062596 Footrest Support Assembly, 90 Degree, Sector,
Color - Right 1 1 9 A,D
8881062597 Footrest Support Assembly, 90 Degree, Sector,
Color - Left 1 1 9 A,D
8881038231 Kit, 3" Extension w/ Hardware (Pair) 1 1 10 A
1026703 Kit, Pivot/Slide Tube Mounting Hardware (Pair) 1 1 11
52
