Footrest Support Assemblies
(Swingaway 60 Degree, 70 Degree, and 90 Degree)
Item
Number Part Number Description Note
Quantity Per
Package Assembly
1045267 Screw, Hex Head w/ Patch (1/4-20 x 3/4") 1 1 12
1026099 Spacer, Coved (1/4 x 11/16 x 1/2") 1 1 13 E
1020534 Insert, Threaded 1 1 14 F
1074143 Kit, Slide Tube Mounting Hardware 1 1 15
1070759 Screw, Hex Head (1/4-20 x 1-1/2") 1 1 16
1044214 Nut, Hex with Nylon Cap (1/4-20) 1 1 17
1026987 Guard, Impact (8" L) 1 1 B,G
A - Specify frame color when ordering.
B - Not Shown
C - Uses Item Number 2, Plug Button 1029501
D - Uses Item Number 2, PLug Button 1056328
E - Item 16 uses 2 per Assembly
F - As of 8/15/03, the Threaded Insert was revised from 3 to 5 Holes. Threaded Insert is Backward Compatible and does not
require ordering in Pairs.
G - For 70 deg. Tapered Footrest.
NOTE:
53
