Server Board S5000PAL / S5000XAL TPS Appendix B: Sensor Tables
Revision 1.4
Intel order number: D31979-007
93
Sensor
Name
Sensor
Number
System
Applica-
bility
Sensor Type Event /
Reading
Type
Event Offset
Triggers
Criticality Assert /
De-assert
Readable
Value /
Offsets
Event Data Rearm Standby
Power
Gauge
V1 rail
(+12v)
Power
Supply 2 7Bh Chassis-
specific
Current
03h Threshold
01h [u] [c,nc] Threshold
defined As and De Analog R, T A –
Power
Gauge
(aggre-
gate
power)
Power
Supply 1 7Ch Chassis-
specific
Other Units
0Bh Threshold
01h [u] [c,nc] Threshold
defined As and De Analog R, T A –
Power
Gauge
(aggregate
power)
Power
Supply 2 7Dh Chassis-
specific
Other Units
0Bh Threshold
01h [u] [c,nc] Threshold
defined As and De Analog R, T A –
System
ACPI
Power
State 82h All System ACPI
Power State
22h
Sensor
Specific
6Fh S0 / G0
S1
S3
S4
S5 / G2
G3 mechanical
off OK As – Trig Offset A X
Button 84h All Button
14h Sensor
Specific
6Fh Power button
Reset button OK As – Trig Offset A X
SMI
Timeout 85h All SMI Timeout
F3h
Digital
Discrete
03h 01h – State
asserted Critical As and De – Trig Offset A –
