Connector / Header Locations and Pin-outs Intel
®
Server Board S5000PAL / S5000XAL TPS
Revision 1.4
Intel order number: D31979-007
50
Pin-Side B PCI Spec Signal Pin-Side A PCI Spec Signal
128 GND 128 HSIp(0)
127 GND 127 HSIn(0)
126 HSOp(1) 126 GND
125 HSOn(1) 125 GND
124 GND
124 HSIp(1)
123 GND 123 HSIn(1)
122 HSOp(2) 122 GND
121 HSOn(2) 121 GND
120 GND
120 HSIp(2)
119 GND 119 HSIn(2)
118 HSOp(3) 118 GND
117 HSOn(3) 117 GND
116 GND
116 HSIp(3)
115 GND 115 HSIn(3)
114 HSOp(4) 114 GND
113 HSOn(4) 113 GND
112 GND
112 HSIp(4)
111 GND 111 HSIn(4)
110 HSOp(5) 110 GND
109 HSOn(6) 109 GND
108 GND
108 HSIp(5)
107 GND 107 HSIn(5)
106 HSOp(6) 106 GND
105 HSOn(6) 105 GND
104 GND
104 HSIp(6)
103 GND 103 HSIn(6)
102 HSOp(7) 102 GND
101 HSOn(7) 101 GND
100 GND
100 HSIp(7)
99 +5V 99 HSIn(7)
98 INTB# 98 GND
97 INTD# 97 ZCR_PRSNT_L
96 +5V
96 +5V
95 Reserved 95 +5V
94 +5V
94 ZCR_MSKID_L
93 IOP INTA 93 +5V
92 IOP INTB 92 INTA#
91 GND 91 INTC#
90 CLK3 90 GND
89 GND 89 REQ3#
88 CLK2 88 GND
87 GND 87 GNT3#
86 REQ2# 86 GND
85 GND
85 RST#
84 Reserved 84 GND
83 GND
83 Reserved
KEY KEY
