Dvr90vg, 1connections 2 watching tv/dvd, Initial setting

background image

This unit can record to DVD-R and DVD-RW discs.

DVD-R discs can only be recorded to once, and cannot

be erased. DVD-RW discs can be recorded to and erased

many times.

DVD-R discs can only be recorded in Video mode, while

DVD-RW discs can select a recording format between Video

mode and VR mode.

• We strongly recommend using any DVD-R 8x,

MAXELL DVD-R 16x and DVD-RW 4x disc to assure

good recording quality.

Discs that tested and proven to be compatible with

this recorder:

VERBATIM DVD-R 8x VERBATIM DVD-RW 2x

MAXELL DVD-R 16x

JVC DVD-RW 4x

1

Connections

2

Watching TV/DVD

Follow to the back side of this sheet.

This unit is compatible to play the following discs.

Disc type

Functions

DVD-RW: 1-4x

DVD-R: 2x.4x.8x

DVD-RW

DVD-RW

VR

DVD-RW

DVD-RW

Video

DVD-R

DVD-R

Attributes

8cm/12cm, single-sided, single layer disc
Approx. max. recording time (SEP mode):
600 minutes (4.7GB) (for 12cm)
180 minutes (1.4GB) (for 8cm)

8cm/12cm, single-sided, single layer disc
Approx. max. recording time (SEP mode):
600 minutes (4.7GB) (for 12cm)
180 minutes (1.4GB) (for 8cm)

Playing, limited recording,
limited editing

Playing, limited recording,
limited editing

Playing, recording,
Original/Playlist editing

Disc format

Video mode

VR mode

Video mode

Logo

Disc

Logo

Disc

DVD-VIDEO

DVD-RW (VIDEO/VR mode)

DVD-R (VIDEO mode)

CD-DA (AUDIO CD)

CD-R (CD-DA FORMAT, MP3/WMA files)

CD-RW (CD-DA FORMAT, MP3/WMA files)

The number inside the globe refers to region of the world.

This unit can play DVDs that are labeled for ALL regions or for Region 1.

DVR90VG

2

– 1

Initial Setting

After you have completed connections;

Press the input selector button (usually TV/VIDEO, INPUT or AUX) on your TV to switch an appropriate external input

channel (usually near channel 0) for viewing the picture from this unit.

Please refer to

Input Mode Names for Common TV Brands

on page 15 of the Owner's manual or the manual accompanying

your TV.

DVD Recorder

with Video Cassette Recorder

Playable discs

Region codes

Recordable discs

is a trademark of DVD Format/Logo Licensing Corporation.

1. Turn on the TV and the unit in the

first time. “Initial Setting” will appear.

Using

[K / L], select your desired

language for the OSD. Then press

[ENTER] to go to next step.

2. Press [ENTER] on Channel Preset.

The unit will start getting channels

available in your area.

I

DVD+R/+RW discs can be played back only on this unit.

3. Clock Setting menu will appear.

Press

[ENTER] twice, default date

will appear.

Initial Setting

Français
Español

English

Auto Presetting Now

CH 1

4. Using [K / L], enter the date

(month / day / year).

Press

[{ / B] to move the cursor.

FEB/ 01 / 2006(WED)

12: 00 AM

Initial Setting

JAN/ 01 / 2006(SUN)

12: 00 AM

Initial Setting

5. Using [K / L], enter the time

(hour / minute). Press

[{ / B].

A cursor will move on AM.

6. Press [K / L] to select “AM” or

“PM”. Press

[ENTER].

TV Program will automatically

appear.

Playing, recording, and editing discs

are available on this unit.

FEB/ 01 / 2006(WED)

12: 00 AM

Initial Setting

ANTENNA

IN

IN - AUDIO - OUT

S-VIDEO

S-VIDEO

AUDIO

OUT

DIGITAL

AUDIO OUT

COAXIAL

COMPONENT

VIDEO OUT

IN - VIDEO - OUT

L

Y

OUT

P

B

/C

B

P

R

/C

R

L

R

L

R

R

OUT

DVD/VCR

DVD

IN

(Back of this unit)

[Cable Box or Satellite Box]

IN

OUT

OR

OR

Indoor or

Outdoor Antenna

From Cable

Company

(No Cable Box)

From Cable or

Satellite Company

AUDIO IN

VIDEO

Video

cable

(supplied)

RF

cable

(supplied)

(Back of TV)

Connect

Connect

2

3

Audio

cable

(supplied)

Connect

4

Connect

1

disc tray

guide

Insert a disc.

2

– 2

DVD Playback

Press

[POWER] to

turn the unit on.

Press

[OPEN/CLOSE A]

to open the disc tray.

STOP

POWER

T-SET

TIMER PROG.

SKIP

SKIP

OPEN/CLOSE

SPACE

1

2

3

4

5

6

7

8

0

9

CH

VIDEO/TV

SLOW

PAUSE

.@/:

ABC

DEF

GHI

JKL

MNO

PQRS

REC/OTR

DISPLAY

TUV

WXYZ

DVD

REC/OTR

REC SPEED

ZOOM

SEARCH

VCR

SETUP

CM SKIP

RETURN

MENU/LIST

TOP MENU

DUBBING

x1.3/0.8

CLEAR

ENTER

PLAY

AUDIO

Press

:

DVD

STOP

POWER

T-SET

TIMER PROG.

SKIP

SKIP

OPEN/CLOSE

SPACE

1

2

3

4

5

6

7

8

0

9

CH

VIDEO/TV

SLOW

PAUSE

.@/:

ABC

DEF

GHI

JKL

MNO

PQRS

REC/OTR

DISPLAY

TUV

WXYZ

DVD

REC/OTR

REC SPEED

ZOOM

SEARCH

VCR

SETUP

CM SKIP

RETURN

MENU/LIST

TOP MENU

DUBBING

x1.3/0.8

CLEAR

ENTER

PLAY

AUDIO

Press

[OPEN/CLOSE A]

to close the disc tray.

Press

[PLAY B].

Playback will start.

• Some discs may start

playback automatically.
