APPENDIX
AP-10
4. Parts List and Parts Location
This equipment contains complex modules in which fault diagnosis and repair down to
component level are not practical (IMO A.694(17)/8.3.1. Only some discrete components
are used. FURUNO Electric Co., Ltd. believes identifying these components is of no value
for shipboard maintenance; therefore, they are not listed in the manual. Major modules can
be located on the parts location photo on this and the next page.
F U R U N O
Model SC-110
Unit SC-1101
PROCESSOR UNIT
ELECTRICAL PARTS LIST Ref.Dwg. Page
Blk.No.
SYMBOL TYPE CODE No. REMARKS SHIPPABLE
ASSEMBLY
PRINTED CIRCUIT BOARD
20P8178, MAIN
20P8181, PWR
MAIN Board
(20P8178)
PWR Board
(20P8181)
Processor Unit, cover removed
