9
G e t t i n g t o K n o w Y o u r L i f e B o o k
Figure 2-6. LifeBook notebook right-side panel
RIGHT-SIDE PANEL COMPONENTS
The following is a brief description of your LifeBook
notebook’s right-side components.
Modem (RJ-11) Jack
The Modem (RJ-11) jack is for attaching a telephone
line to the internal multinational 56K modem. (See
Modem (RJ-11) Telephone Jack on page 47 for more infor-
mation)
Flexible Bay
The Flexible Bay can accommodate one of the following
devices. (See Flexible Bay Devices on page 19 for more
information)
■ Modular DVD/CD-RW combo drive:
■ Modular Dual-Layer Multi-Format DVD Writer
■ Modular Lithium ion bay battery
■ Weight Saver
Flexible Bay Eject Lever
The Flexible Bay eject lever releases the Flexible Bay
device.
USB 2.0 Ports
The USB 2.0 ports allow you to connect Universal Serial
Bus devices. USB 2.0 transfers data at up to 480 Mbps
and is backward-compatible with USB 1.1 devices,
which transfer data at up to 12 Mbps. (See Universal
Serial Bus Ports on page 47 for more information)
External Monitor Port
The external monitor port allows you to connect an
external monitor. (See External Monitor Port on page 49
for more information)
Flexible Bay Flexible Bay Eject Lever
Modem (RJ-11) Jack
USB Port
External Monitor Port
The internal modem is not intended for
use with Digital PBX systems. Do not
connect the internal modem to a Digital
PBX as it may cause serious damage to the
internal modem or your entire notebook.
Consult your PBX manufacturer’s
documentation for details. Some hotels
have Digital PBX systems. Be sure to find
out BEFORE you connect your modem.
The internal multinational modem is
designed to the ITU-T V.90 standard. Its
maximum speed of 53000bps is the
highest allowed by FCC, and its actual
connection rate depends on the line
conditions. The maximum speed is
33600bps at upload.
