10
FUNCTIONAL PARTS
Control panel and side panel
(The control panel and side panel shown as below is designed for the C52-WD9000 model.)
Note: Before using these input jacks, please refer to the INSTRUCTION MANUAL on page 48.
I
N
5
T
U
P
O
I
D
A
U
MENU/RETURN button
POWER button
POWER indicator
Remote control sensor
PROGRAM UP/DOWN
buttons
(When the menu
appears on the screen, press
PROG
Ÿ/ PROGź buttons
to select the menu up and
down.)
TV/VIDEO selector
Side panel input jacks
(For AV5 input)
VOLUME UP/DOWN
buttons
(When the menu
appears on the screen,
press VOL
Ż / VOLŹ
buttons to select the
menu left and right.)
MAGIC FOCUS button
