NOTE:

NOTE: This section lists some of the steps required to configure a Factory Integrated Model. To ensure only valid configurations are
ordered, HP recommends the use of an HP approved configurator. Contact your local sales representative for additional
information.
NOTE:

NOTE:

NOTE: HP does not allow factory integration of options into standard models listed above. Configure-to-order servers must start
with a CTO Chassis.
NOTE:

NOTE:

NOTE: This product offering does not support HP Factory Express Server Configuration Level 1.
NOTE:

NOTE:

NOTE: FIO indicates that this option is a Factory Installable Option.

Step 1: Base Configuration (choose one of the following configurable models)

Non-Hot Plug Model

HP ProLiant DL160 G5 Non-Hot Plug SATA Rack CTO Chassis

445192-B21

Factory Integrated Model ships with:

Two embedded NC105i PCIe Gigabit Server Adapters (WOL & PXE-capable)
Two available PCI-Express 2 slots:

Slot 1: full-length/full-height
Slot 2: low-profile/half-height

650 Watt Power Supply

One Highline IEC Power Cord

6 Non-Hot Plug Fans

Rack (1U), (1.75 in / 4.45 cm)
Fixed Rails

Hot Plug Model

HP ProLiant DL160 G5 Hot Plug SAS/SATA Rack CTO Chassis

445193-B21

Factory Integrated Model ships with:

Two embedded NC105i PCIe Gigabit Server Adapters (WOL & PXE-capable)

Two available PCI-Express 2 slots:

Slot 1: full-length/full-height
Slot 2: low-profile/half-height
650 Watt Power Supply

One Highline IEC Power Cord

6 Non-Hot Plug Fans

Rack (1U), (1.75 in / 4.45 cm)
Fixed Rails

QuickSpecs

HP ProLiant DL160 Generation 5 (G5)

Configuration Information - Factory Integrated Models

DA - 12902 Worldwide — Version 15 — August 1, 2008
