Huffy 89225 User Manual
Page 7
7
P/N 21154401
01/04
At corner locations 1, 2, and 3 install the display pole to the mounting pole stub. If required,
secure the display pole by sliding the display wedge (12) into position as shown. To lock the
display pole in place, tighten the set screw (13 or 39).
At corner location 4 slide the display pole (14) (3 1/2” diameter) over the mounting pole stubs.
12: QTY 3
39: QTY 1
13: QTY 2
10
1.
2.
