44” FAN MOLDED PLASTIC BOARD ASSEMBLY - Corner Location 2
Correctly identify each pole section.
ONLY THE TOP POLE SECTION (14) IS USED IN THIS ASSEMBLY.
1.
BOTTOM POLE 43”
MIDDLE POLE 43”
TOP POLE 31”
14
Fit spacer (15) into pawl (19). Then continue to assemble as shown. Tighten completely.
2.
15
15
18
24
23
64
19
21
Elevator tube
Toward
Pole
Toward
Board
Identify elevator tubes (21).
3.
17
