Title: A. Ice Dispenser Assembly Model: DKM-500BWH
Index
No. Description
Material or
Model Number Part Number
Required Number
T-0
T-1
U-0
U-1
to
V-5
V-6
to
A-5 A-6
B Refrigeration Unit - 1A1480A01 1 1 -
1A1480A02 1 -
1A2086A01 1 1
C Water Circuit - 2A3808A02 1 1 -
2A5136A02 1 1 1
D Control Box Assembly - 2A4574A01 1 1 -
2A4574A02 1 -
2A6214A01 1 1
D1 FT Screw 4×8, SS 7F32-0408 4 4 4 4 4
E Bin Assembly - 2A3581A02 1 1 1 1 -
2A3581A03 1
E1 Hex Bolt w/Washer (LF) 8×20, SS 7B0230820 4 4 4 4 4
E2 FT Screw 4×8, SS 7F32-0408 3 3 3 3 5
F Bin Cover Assembly - 3A3877A01 1 1 1 1 1
F1 Thumbscrew ABS, SS 434168G02 3 3 3 3 3
G Front Panel Assembly - 3A3582A01 1 1 1 1 1
G1 FT Screw 4×8, SS 7F32-0408 1 1 1 1 1
H Label Location - 2A3768A02 1 1 1 -
2A6099A02 1 1
1 Frame - 1A1177G01 1 1 -
Frame (includes item 33) 1A1177G02 1 1 1
1a FT Screw 4×8, SS 7F32-0408 3 3 3 3 3
2 Rear Frame (A) - 2A3527-01 1 1 1 1 1
2a FT Screw 4×8, SS 7F32-0408 7 7 7 7 7
3 Side Frame (R) - 1A1075-01 1 1 -
1A1878-01 1 1 1
3a FT Screw 4×8, SS 7F32-0408 5 5 5 5 5
4 Side Frame (L) - 3A3584-01 1 1 1 1 1
4a FT Screw 4×8, SS 7F32-0408 4 4 4 4 4
5 Square Washer Brass 433537-02 1 1 1 1 1
6 Ground Screw - 433304-02 1 1 1 1 1
7 Bushing SR-7K-2 420472-02 1 1 1 1 1
8 Power Supply Cord - 4A0520-01 1 1 1 1 1
9 Side Panel w/clip - 4A4483G01 2 2 2 2 2
9a FT Screw 4×8, SS 7F32-0408 11 11 11 11 11
10 Evaporator Case - 2A3586G01 1 1 1 1 1
10a FT Screw 4×8, SS 7F32-0408 4 4 4 4 4
11 Side Panel-(L1) SS 2A3532G01 1 1 1 1 1
11a FT Screw 4×8, SS 7F32-0408 1 1 1 1 1
12 Side Panel-(R1) SS 2A3529G01 1 1 1 1 1
12a FT Screw 4×8, SS 7F32-0408 1 1 1 1 1
13 Top Panel Assembly - 3A3583G01 1 1 1 1 1
14 Rear Panel - 2A4484-01 1 1 1 1 1
14a FT Screw 4×8, SS 7F32-0408 4 4 4 4 4
15 Hook - 4A3984-01 1 1 1 1 1
