Title: A. Ice Dispenser Assembly Model: DKM-500BAH
Index
No. Description
Material or
Model Number Part Number
Required Number
R-0
R-1 S-0
S-1
T-0
T-1
U-0
U-1
to
V-6
V-7
A-5 A-6
14 Rear Panel - 3A3586-01 1 1 1 1 1 1 1
14a FT Screw 4×8, SS 7F32-0408 4 4 4 4 4 4 4
15 Hook - 4A3984-01 1 1 1 1 1 1 1
16 Air Filter - 2A2062G01 2 2 2 2 2 2 2
17 Drain Pan Assembly - 2A3522G01 1 1 1 1 1 1 1
17a FT Screw 4×8, SS 7F32-0408 4 4 4 4 4 4 4
18 Fitting-Drain - 438729-01 1 1 1 1 1 1 1
18a Truss Head Screw 5×8, SS 7C32-0508 2 2 2 2 2 2 2
19 Tee PVC 4A0525-05 1 1 1 1 1 1 1
20 Hose Clamp 2346 HC 1250 4A2017-03 4 4 4 4 4 4 4
21 Vinyl Hose-Clear L=195 4A0658L01 1 1 1 1 1 1 1
22 Vinyl Hose-Clear L=170 4A0658L01 1 -
L=192 1 1 1 1 1 1
23 Vinyl Hose L=550 7716-2025 1 1 1 1 1 1 1
24 Hose Clamp 2338 HC 953 4A2017-01 2 2 2 2 2 2 2
25 Insulation Panel - 2A0664G01 1 1 1 1 1 1 1
26 Top Insulation - 215730G01 1 1 1 1 1 1 1
27 Wire Saddle VWS4274-C 4A0338-03 5 5 5 5 5 5 5
28 Evaporator Bracket - 4A4068-01 1 1 1 1 -
29 Bushing OCB-875 428394-04 1 1 1 1 1 1 1
30 Bushing SB-1500-21 420470-06 1 1 1 1 1 1 1
31 Rubber Gasket L=50 4A0662L01 1 1 1 1 1 1 1
32 Front Panel Support - 4A4133G01 1 1 1 1 1 1 1
33 Evaporator Case - 2A3586G01 1 1 1 1 1 1 1
33a FT Screw 4×8, SS 7F32-0408 4 4 4 4 4 4 4
34 Side Panel (L) (includes 1 of
item 10 and 3 of item 10a) - 3A4355A01 1 1 1 1 1 1
34a FT Screw 4×8, SS 7F32-0408 5 5 5 5 5 5
35 Locking Hole Plug - 4A0586-04 1 1 1 1
36 Compressor Base Assembly - 4A4835G01 1 1 1
