Hoshizaki DKM-500BWH - Manual (Page 20)

20
Title: B. Refrigeration Unit Model: DKM-500BWH
Index
No. Description
Material or
Model Number Part Number
Required Number
T-0
to
U-0
U-1
to
V-6
V-7
to
A-6
35 Drier 4A2666-01 1 1 1
36 Pressure Switch Bracket GS 434938-01 1 1 -
36a FT Screw 4×8, SS 7F32-0408 1 1 -
37 Pressure Switch ACB-2UB04 433441-05 1 1 -
- 463180-05 1
38 Elbow - 4A1059-01 1 1 1
39 Elbow - 417395-03 1 1 1
40 Tee - 436000-08 1 1 1
41 Insulated Rubber Tube - 4A1008G01 1 1 1
42 Insulation Holder SS 4A3902-01 1 1 1
43 Insulation Tube L=180mm 7762-0717 1 1 -
L=150mm 1
44 Insulation Tube L=170mm 7762-1030 1 1 1
45 Insulation Tube L=50mm 7762-2030 5 5 5
46 Insulation Tube L=385mm 7762-2040 1 1 1
47 Cable Tie - 8911-0150 16 16 15
