LIST
PARTS
ITEM NO.
37
Bearing Half
301030
0
1
38
Jockey Arm Assembly
301015
0
1
39
Pulley - Tensioner
239021
0
1
40
Screw - 6 x 16 Pozidrive
09634
2
2
41
Adapter
MU42734
1
1
42
Cutterbar
302026
1
1
43
Washer
MU17x137
1
1
44
Plate - Securing
219037
3
3
45
Washer - M4
09658
1
1
46
Bolt - Hex Hd 3/8" x 1.1/2" UNF
09118
1
1
47
Rod - Connecting
305109
1
1
48
Screw - Hex W/Hd M6 x 12
09546
4
5
49
Hub Cap
219143
2
2
50
Nut - Wheel 1/2" Nyloc
4486
2
2
51
Wheel - 6"
302016
2
2
inc. item 92
52
Axle - Front Assembly
300111
1
1
53
Rear Roller Frame
306115W
0
1
Rear Roller Frame
308050W
1
0
54
Roll Pin
03997
0
1
55
Clutch Lever
306094W
0
1
56
Handlebar - Upper
305091W
1
1
57
Lever - Engine Stop
340179
1
1
58
Pivot Pin
340182
2
2
59
Washer - Nylon
09688
6
2
60
Screw - 6mm x 20
09687
2
3
61
Drive Fastener
300144
2
2
62
Cable - Clutch
306107
0
1
63
Bracket - Clutch Cable
306108
0
1
64
Rope Guide
305127
1
1
65
Cable - Engine Break
312002
0
1
66
Screw - M5x35
09358
?
?
67
Screw - M4x35
09704
0
1
68
Cable Tie
3966
3
3
69
Rope Guide
305093
1
1
70
Tube Plug
300160
2
2
71
Bolt - Saddle Hd M8 x 45
226024
2
2
72
Knob
226013
2
2
73
Nut - Cap M8
234051
2
2
74
Nut - Nylon Ins. 'T' Type M8
09441
2
2
75
Handlebar - Lower
300062
2
2
76
Deflector
305102
1
1
QTY.
308A 312A
DESCRIPTION
PART NO.
ITEM NOTE
