1.24
Remove grass debris from the top and underside of the deck housing
immediately after use.
To prevent accidents fertilisers and top dressings are particularly
corrosive. Thoroughly clean the mower deck immediately after use
on treated grass and store well away from corrosive materials.
Regularly check that all securing nuts and bolts are tight. Replace
missing or damaged items immediately.
Auto Drive Model Only.
Check the clutch cable operation every 25 operating hours and adjust
if necessary. The clutch cable is adjusted correctly when the belt drive
just engages with the clutch lever positioned 32-38mm from the han-
dlebar.
Unscrew the lock nuts (1) and screw the adjuster (2) in or out as nec-
essary. Tighten the locknuts (1) when correctly adjusted.
32-38mm
1
2
1CG480V36B
Securing Nuts & Bolts
Deck Housing
Clutch Cable Adjustment
MOWER MAINTENANCE
