1 Deck 305101V 1 1
2 Key 1662 1 1
3 Engine - Compliance 312004 0 1
Engine - Compliance 308054 1 0
4 Bracket - Scraper 306120 0 1
5 Pulley 306123 0 1
6 Screw - Pan. Pozi Taptite M6 x 16 09596 6 6
7 Height Adjuster Handle 305112 1 1
8 Decal - Engine 6298 1 1
9 Screw - UNC Taptite 3/8" x 1.1/4" 09349 3 3
10 Decal - Height of Cut 305113 1 1
11 Decal - Grass Blade 410064 1 1
12 Decal - Hayter / Royal Warrant 410087 1 1
13 Decal - Serial No. - 1 1
14 Spring 301031 0 1
15 Trigger 300066 1 1
16 Trigger Spring 300067 1 1
17 Axle Bolt 308021 1 1
18 Compensating Spring 300070 1 1
19 Washer - M6 Plain 09472 6 7
20 Pillar 300137 1 1
21 Nut - M6 Nylon Ins 'T' Type 09544 2 2
22 Rear Roller 201007 2 0
Rear Roller 239065 0 1
23 Throwplate 300124 1 1
24 Axle Bush 305108 2 2
25 Belt - V 306050 0 1
26 Driven Pulley 306102 0 1
27 Screw - No 10 x 3/4" 09706 0 4
28 Ferrule 305115 2 2
29 Washer - 3/8" Plain (Axle Spacers) 09271 1 1 As required
30 Nut - 3/8" UNF Nylon Ins. 'T' Type 09216 1 1
31 Nut - M4 Nyloc Ins ‘T’ Type 09657 0 1
32 Axle Support 305130 1 1
33 Compensating Pulley 301020 0 1
34 Compensating Plate 301050 0 1
35 Grip-Fix 02385 2 3
36 Grip-Fix 04020 0 2
1.31
PARTS LIST
ITEM NO.
QTY.
308A 312A
DESCRIPTION PART NO. ITEM NOTE
