English - 67
7. GARDEN EXAMPLE
Area: 0.12 acre. There are several islands.
No guide wire is necessary. The mower’s
default settings do not need to be changed.
Timer: Operating time of 7 hours per day.
Exit angles: One sector 90°- 270°.
Search method: Irregular.
Delay: Guide 1 7 minutes, Guide 2 7 minutes
and boundary wire 11 minutes.
Corridor width: 6.
Area: 0.25 acre. There is one small island.
Guide wire recommended through the
passage.
Timer: Operating time of 14 hours per day.
Exit angles: One sector 70°-190°.
Follow loop out: Direction Guide 1, Distance
20 m (65 ft) and Proportion 25 %.
Search method: Irregular, Follow guide wire
in and Follow boundary wire in.
Delay: Guide 1 7 minutes, Guide 2 7 minutes
and boundary wire 11 minutes.
Corridor width: Guide 1 6, boundary wire 20.
This example only applies to 230 ACX.
Area: 0.5 acre. Two guide wires are
recommended.
Timer: Operating time of 19 hours per day.
Exit angles: One sector 90°-270°.
Follow loop out: Area 1; Direction Guide 1,
Distance 30 m (98 ft) and Proportion 15 %.
Area 2; Direction Guide 2, Distance 30 m
(98 ft) and Proportion 30 %.
Search method: Irregular, Follow guide wire
in and Follow boundary wire in.
Delay: Guide 1 2 minutes, Guide 2 2 minutes
and boundary wire 11 minutes.
Corridor width: Guide 1 4, Guide 2 4 and
boundary wire 6.
Proposals for installation and settings
3012-527US
3012-528US
3012-743US
