Integrated Intel
Graphics Media
Accelerator (GMA) 4500 3D/2D Controller Microsoft DirectX® 10 based with support for Pixel Shader 2.0
VGA Controller Integrated
Bus Type PCI Express™ x16 (If an external graphics card is installed in a PCI
slot, the internal graphics can be enabled or disabled using the system's
BIOS setup utility. If an external graphics card is installed in the PCI
Express™ slot, the internal graphics cannot be enabled).
RAMDAC Integrated, 350 MHz
Memory Graphics memory is shared with system memory. Graphics memory
usage varies depending on the amount of system memory installed and
system load. 8 MB is pre-allocated for graphics use at system boot time.
Additional memory is allocated for graphics as needed using Intel's
Dynamic Video Memory Technology (DVMT), to provide an optimal
balance between graphics and system memory use.
System memory equal or greater than 512 MB
8 MB pre-allocated + 248 MB DVMT = max frame buffer of 256 MB
Controller Clock Speed 250 MHz
Overlay Planes Single overlay support with 5x3 filtering
Maximum Color Depth 32 bits/pixel
Maximum Vertical
Refresh Rate 75 Hz at up to 2048 x 1536 analog, 60 Hz at up to 1920 x 1200 for flat
panel, 85 Hz at up to 1400 x 1050 for digital CRT/HDTV. Varies with
mode and configuration. See table below.
Multi-display Support Support for one CRT via the motherboard's VGA connector. Support for
an additional DVI-D display via the optional DVI ADD2 card. Dual
independent displays and dual synchronous (Twin or Clone mode)
displays are supported.
Graphics/Video API
Support Microsoft DirectX® 10, DirectXVA®, VMR9, GDI/GDI+; OpenGL® 1.4.
Resolutions
Supported
1
Resolution Maximum Refresh Rate (Hz)
Analog Monitor Digital Monitor
Flat Panel CRT / HDTV
640 x 480
800 x 600
1024 x 768
1280 x 1024
1400 x 1050
1600 x 1200
1920 x 1080
1920 x 1200
1920 x 1440
2048 x 1536
75
75
75
75
75
75
75
75
75
75 60
60
60
60
60
60
60
60
N/A
N/A
85
85
85
85
85
N/A
N/A
N/A
N/A
N/A
1 Modes listed are supported with a single active display. The supported mode list for multiple active displays is a subset of
this list. Not all modes will support video playback and some supported modes may use software MC (motion compensation)
rather than hardware MC. Not all modes will support 3D acceleration depending on the system configuration (e.g., resolution
selected, size of frame buffer, number of installed memory modules, etc.).
NOTE: Other resolutions and refresh rates may be selectable but are not recommended.
ATI Radeon HD 4350
HDMI PCIe x16
Graphics Card Input/Output
connectors DVI
VGA and HDMI
Board display options Supports two displays through any combination of two of the three output
ports.
QuickSpecs
Compaq 500B Microtower PC
Technical Specifications - Graphics
DA - 13418 Worldwide QuickSpecs — Version 2 — 10.30.2009 Page 19
