Page 2: Cleaning the overflow filter
Wipe the complete unit with soft
cloth twisted dry.
Wipe with neutral detergent if too dirty
Do not wash it directly by water
After washing, dismount the water inlet
hose.
Do not store water in the tub for long
period. Discharge the water immediately
after each using.
Pull off the power plug and hang up the
power cord.
Hang up the drain hose.
Wipe off the water drops on the surface
and inside the tub with clean soft cloth.
Open the cover of the wash tub and the
inner/outer cover of the spin tub for
some time (about one hour), then close
them.
Disposal of the complete unit
Thinner
Alcohol
Petrol
13
W
ater inlet hose
Gland
Packing list
Semi Auto washing machine
Name
Quantity
User's manual
One piece
One piece
One piece
One set
Specification
W
ater
level
W
ater
quantity
estimated
(L)
Maximum/89
Medium/75
M
inimum/63
Injection pressure(MPa)
0.02~0.2
Spinning capacity(kg)
6.0
Rated voltage frenquency
220V 50Hz
Specifications may be subject to change
without prior notice
*
Cleaning the overflow filter
2. T
ake off the corrugation pipe.
Dismantle the upper part of the
corrugation pipe inside the
overflow filter ( as indicated in
Figure 1).
3. Cleaning the overflow filter
Clean the lint around the filter
and flush with tap water.
4. Install the overflow filter.
(1).Install the corrugation pipe.
(2).Insert the mounting plate at
the bottom of the filter into
the valve cover.
(3).Hang up the hook at the left
upper side.
(4).Push the upper part in as
indicated in Figure 2.
Washing
capacity(kg)
12.0
Figure 1
Figure 2
Hook
Water level
adjusting lever
Corrugation
pipe
