Havis-Shields Vehicle Specific Console C-VS-1800-ESC-1 User Manual
Always, 2008 ford escape vehicle specific console

1
C-VS-1800-ESC-1_INST_1-08
INSTALL INSTRUCTIONS C-VS-1800-ESC-1
2008 FORD ESCAPE
VEHICLE SPECIFIC CONSOLE
• Phillips Screw driver
• T-20 Torx Bit
• Ratchet Wrench
• 7mm, 10mm sockets
TOOLS REQUIRED:
QTY: DESCRIPTION:
PART
#:
18
8 x 1/4” Flat Head Phillips SMS
GSM33187
2
3/4” Plugs
GSM 20016
1
Torx
screws
C-HK-1
2
Bracket, Spacer, Front Gear Box Console CM002140
1
Bracket, Cons, Fuse Cover
CM002142
1
Bracket,
Cover,
Shift
Gear
Box
CM002150
1
Panel, DS, Front Console, Shift Gear Box CM002151
1
Panel, PS, Front Console, Shift Gear Box
CM002152
HARDWARE:
Always!
• Read all instructions before installing any Havis-Shields Equipment Corp products.
• Check for obstructions (Wire, brake lines, fuel tank, etc.) before drilling any holes!
• Use hardware provided with install kit
• For product support: visit the Install Instructions Section of our website at
http://havis.com/Installation/Installation.html, email [email protected]
or call 1-800-524-9900.
LINE DRAWING:
