Quickspecs – Hood WORKSTATION HP Z600 User Manual

Page 45

ATI FirePro V7750 1.0GB

ATI FirePro V7750 1.0GB
Graphics Card

Graphics Card

Form Factor

4.40 inches (H) × 13.0 inches (L) (11.18 cm (H) × 33.02 cm (L))

Graphics Controller

ATI FirePro V7750 Graphics Board

Bus Type

PCI Express x16, Generation 2.0

Memory

1024 MB GDDR3 SDRAM unified graphics memory

Connectors

2 DisplayPort, 1 Dual-Link DVI-I.
One DisplayPort to DVI and one DVI to VGA adapter included
('DisplayPort to VGA' and 'DisplayPort to Dual Link DVI' adapters available as
an accessory)

Maximum Resolution

Two DisplayPort outputs drive two digital displays up to 2560 x 1600
One dual-link DVI-I output drives one digital display at resolutions up
to 2560 x 1600 @ 60Hz or one analog display at resolutions up to
2048 x 1536 @ 85Hz

Shading architecture

Full Shader Model 4.0

320 Stream Processing Units
Dynamic load balancing and resource allocation for vertex, geometry,
and pixel shaders
Common instruction set and texture unit access supported for all types
of shaders
Dedicated branch execution units and texture address processors

Supported graphics APIs

OpenGL 2.1
DirectX 10.1

Available graphics drivers

Available graphics drivers Genuine Windows Vista Business (64-bit and 32-bit)

Microsoft Windows XP Professional (64-bit and 32-bit)

HP qualified drivers may be preloaded or available from the HP support
Web site:

http://welcome.hp.com/country/us/en/support.html

Linux drivers may be obtained from:

http://ati.amd.com/support/driver.html

Power consumption

76 Watts

QuickSpecs

HP Z600 Workstation

Technical Specifications - Graphics

DA - 13277 North America — Version 2 — April 13, 2009

Page 45
