ATI FirePro V3700 ATI FirePro V3700 ATI FirePro V3700 ATI FirePro V3700
256MB Graphics Card
256MB Graphics Card 256MB Graphics Card 256MB Graphics Card
Form Factor Form Factor Form Factor Form Factor 4.40 inches (H) × 6.70 inches (L) (11.18 cm (H) × 17.02 cm (L))
Graphics Controller Graphics Controller Graphics Controller Graphics Controller ATI FirePro V3700 Graphics Board
Bus Type Bus Type Bus Type Bus Type PCI Express x16, Generation 2.0
Memory Memory Memory Memory 256 MB GDDR3 SDRAM unified graphics memory
Connectors Connectors Connectors Connectors 2 Dual Link DVI-I
Two DVI-I to VGA adapters included
Maximum Resolution Maximum Resolution Maximum Resolution Maximum Resolution Two dual-link DVI-I outputs drive two digital displays at resolutions up to
2560 x 1600 @ 60Hz or two analog displays at resolutions up to 2048 x
1536 @ 85Hz
Shading architecture Shading architecture Shading architecture Shading architecture Full Shader Model 4.0
40 Stream Processing Units
Dynamic load balancing and resource allocation for vertex, geometry,
and pixel shaders
Common instruction set and texture unit access supported for all types
of shaders
Dedicated branch execution units and texture address processors
Supported graphics APIs Supported graphics APIs Supported graphics APIs Supported graphics APIs OpenGL 2.1
DirectX 10.1
Available graphics drivers Available graphics drivers Available graphics drivers Available graphics drivers Genuine Windows Vista Business (64-bit and 32-bit)
Microsoft Windows XP Professional (64-bit and 32-bit)
HP qualified drivers may be preloaded or available from the HP support
Web site:
http://welcome.hp.com/country/us/en/support.html
Linux drivers may be obtained from:
http://ati.amd.com/support/driver.html
Power consumption Power consumption Power consumption Power consumption 32 Watts
NVIDIA Quadro FX 580 NVIDIA Quadro FX 580 NVIDIA Quadro FX 580 NVIDIA Quadro FX 580
512MB Graphics Card
512MB Graphics Card 512MB Graphics Card 512MB Graphics Card
Form Factor Form Factor Form Factor Form Factor 4.376 inches (H) × 6.60 inches (L)
Graphics Controller Graphics Controller Graphics Controller Graphics Controller NVIDIA Quadro FX 580 Graphics Board
Bus Type Bus Type Bus Type Bus Type PCI Express x16, Generation 2.0
Memory Memory Memory Memory 512MB GDDR3 SDRAM unified graphics memory
Connectors Connectors Connectors Connectors 2 DisplayPort, 1 Dual-Link DVI-I.
One DisplayPort to DVI and one DVI to VGA adapter included
('DisplayPort to VGA' and 'DisplayPort to Dual Link DVI' adapters available as
an accessory)
Maximum Resolution Maximum Resolution Maximum Resolution Maximum Resolution Two DisplayPort outputs drive two digital displays up to 2560 x 1600
One dual-link DVI-I output drives one digital display at resolutions up
to 2560 x 1600 @ 60Hz or one analog display at resolutions up to
2048 x 1536 @ 85Hz
RAMDAC RAMDAC RAMDAC RAMDAC Single Internal 400 MHz DAC
Shading architecture Shading architecture Shading architecture Shading architecture Full Shader Model 4.0 (OpenGL 2.1/DirectX 10 class)
Long fragment programs (unlimited instructions)
QuickSpecs
HP Z600 Workstation HP Z600 Workstation HP Z600 Workstation HP Z600 Workstation
Technical Specifications - Graphics
DA - 13277 North America — Version 2 — April 13, 2009 Page 41
