**SATA hardware RAID is not supported on Linux systems. The Linux kernel, with built-in software RAID,
provides excellent functionality and performance. It is a good alternative to hardware-based RAID. Please
visit

http://h20000.www2.hp.com/bc/docs/support/SupportManual/c00060684/c00060684.pdf

for

RAID capabilities with Linux.

Form Factor

Rackable Minitower

Color

Black/Silver

I/O Slots

I/O Slots (see system
board section for more
details)

2 PCI Express Gen2 x16 slots (full-length, full-height)
1 PCI Express Gen2 x8 slot - with x8 connectors (full-length, full-height)
1 PCI Express Gen1 x8 slot - with x8 connectors (full-length, full-height)
2 PCI 32bit/33MHz slot, (full-length, full-height)
The PCIe x8 connectors are open ended, allowing a PCIe x16 card to be seated in the slot.

Bays

Bays (see storage section
for more details)

Total Bays = 4

Internal Bays

2 internal 3.5" bays (with acoustic dampening rail assemblies)

External Bays

2 external 5.25" bays
(3rd & 4th HDDs occupy one external bay)

Front I/O

3 USB 2.0, 1 Headphone Out, 1 Microphone In, and 1 IEEE 1394a
(For front 1394a port to function, optional 1394 card must be installed.)

Rear I/O

6 USB 2.0
1 RJ-45 to integrated Gigabit LAN
2 legacy PS/2
1 Audio Line In, 1 Audio Line Out, 1 Microphone In; audio ports can be retasked to function as line in,
line out, microphone, or headphone.
Serial supported with optional rear bulkhead adapter.

Internal USB

3 USB 2.0 headers

Chassis Dimensions

Chassis Dimensions (W x
D x H)

17.5 x 6.5 x 17.3 in (44.51 x 16.53 x 44 cm)

Weight

Exact weights depend upon configuration
Minimum config – 33.0 lb (15.0 kg)
Typical config – 37.4 lb (16.9 kg)
Maximum config – 43.3 lb (19.6 kg)
(Maximum shipping weight – 52.0 lb / 23.6 kg)

Temperature

Operating:

40° to 95°F (5° to 35°C)

Non-operating

–40° to 140° F (–40° to 60° C)

Humidity

Operating:

8% to 85%

Non-operating

8% to 90%

Maximum Altitude

Maximum Altitude (non-
pressurized)

Operating:

10,000 feet; 3,000 m

Non-operating

30,000 feet; 9,100 m

Power Supply

650W 85% (80PLUS Bronze) Efficient wide-ranging, active Power Factor Correction, with tool-free &
cable-free connection

Interfaces Supported

6-channel SATA 3.0 Gb/s Interface (6 Serial-ATA connectors on the motherboard, 4 channels are eSATA
configurable for use with eSATA CTO/AMO Kit)
SAS interface supported with optional LSI 3041E 4-port SAS/SATA PCIe card.
1 Floppy interface (1 Floppy connector), USB 2.0

Hard Drive Controllers

Hard Drive Controllers
Supported

Supported

SATA and SAS controllers

QuickSpecs

HP Z600 Workstation

Overview

DA - 13277 North America — Version 2 — April 13, 2009

Page 4
