Important – Huffy AR325W User Manual
Page 17
01/04
P/N 214955E
17
47
42
40
41
40
55
57
57
34
39
Attach rim to board as shown. For spring loaded rim assembly, refer to instructions
included with rim hardware. Assemble lower elevator tubes (40) as shown. DO NOT
overtighten.
IMPORTANT!:
Refer to instructions
included with board and rim
hardware for backboard and
rim assembly.
IMPORTANT!:
It is necessary for all
parts to be installed for
this mechanism to work
safely and properly.
