Huffy AR325W - Manual (Page 15)

01/04 P/N 214955E
15
30
29
16
28
28
Apply logo and height indicator labels (29) to
adjustment rod (28) as shown. Attach handle
parts (32, 33) to adjustment rod with screw
(31), carriage bolt (30), and flange nut (16) as
shown.
Insert handle assembly through pole
mount assembly as shown. Lock
pole assembly in place at the 10’
(3.05 m) mark with pin (26).
Indicator labels
should be applied
as close to holes
as possible to
prevent labels from
being damaged
during height
adjustment.
IMPORTANT!:
31
30
16
26
