HP Compaq dc7900 - Manual (Page 2)

HP Compaq dc7900 Desktop PC series
HP recommends Windows Vista® Business.
Form factor Convertible Minitower Small Form Factor Ultra-slim desktop
Operating system Genuine Windows Vista® Business 32-bit
Genuine Windows Vista® Business 64-bit
Genuine Windows Vista® Home Basic 32-bit
Genuine Windows Vista® Business with downgrade to Windows XP Professional custom installed
FreeDOS
Processor Intel® Pentium® Dual Core E5200 (2.50 GHz, 2
MB L2 cache, 800 MHz FSB) or Intel® Core™2
Duo Processor E7300 / E7400 / E8400 / E8500
/ E8600 (2.66 to 3.33 GHz, 3 to 6 MB L2 cache,
1066 to 1333 MHz FSB) or Intel® Core™2 Quad
Q9400 (2.66 GHz, 6 MB L2 cache, 1333 MHz
FSB)
Intel® Pentium® Dual Core E2200 / E5200 (2.20
to 2.50 GHz, 1 to 2 MB L2 cache, 800 MHz FSB)
or Intel® Core™2 Duo Processor E7300 / E7400 /
E8400 / E8500 / E8600 (2.66 to 3.33 GHz, 3 to
6 MB L2 cache, 1066 to 1333 MHz FSB) or Intel®
Core™2 Quad Q9400 (2.66 GHz, 6 MB L2
cache, 1333 MHz FSB)
Intel® Pentium® Dual Core E2200 / E5200 (2.20
to 2.50 GHz, 1 to 2 MB L2 cache, 800 MHz FSB)
or Intel® Core™2 Duo Processor E7300 / E7400 /
E8400 / E8500 / E8600 (2.66 to 3.33 GHz, 3 to
6 MB L2 cache, 1066 to 1333 MHz FSB)
Chipset Intel® Q45 Express
Memory From 1 GB to 16 GB DDR2-Synch DRAM PC2-6400 non-ECC (single or dual channel configurations) From 1 GB to 8 GB DDR2-Synch DRAM PC2-6400
non-ECC (single or dual channel configurations)
Hard drive(s) 80, 160, 250 or 500 GB (3.5”) SATA 3.0GB/s with NCQ and Smart IV 80 GB and 250 GB SATA 3.0 Gb/s 7200 rpm
Removable media SATA DVD-ROM Drive, SATA SuperMulti LightScribe DVD Writer Drive HP Slim 8X SATA DVD-ROM Drive, HP Slim 8X
SATA SuperMulti LightScribe Drive
Expansion bays 3 external 5.25 inch, 1 external 3.5 inch, 2 internal
3.5 inch
1 external 5.25 inch, 1 external 3.5 inch, 1 internal
3.5 inch
1 Slimline Drive Bay, 1 internal 2.5 inch
Expansion slots 3 full-height PCI, 1 full-height PCI Express x16, 2
full-height PCI Express x1
1 low-profile PCI, 2 low-profile PCI Express x16, 1
low-profile PCI Express x1
1 mini PCIe
Memory slots 4 DIMM 2 SODIMM
Graphics
Intel® Graphics Media Accelerator 4500 integrated graphics
Audio Integrated HD audio with ADI1884 codec, internal PC speaker
Communications Integrated Intel® 82567LM Gigabit Network Connection
I/O ports and connectors Rear: 6 USB 2.0, 1 serial port, 2 PS/2, 1 RJ-45, 1 VGA, 1 DisplayPort, audio in/out; Front: 2 USB 2.0,
audio ports; Optional: 2nd serial port, 1 parallel port
Rear: 6 USB 2.0, 1 DisplayPort, 2 PS/2, 1 RJ-45, 1
VGA, audio in/out; Front: 2 USB 2.0, audio ports
Software Optional preloaded software, only for certain configurations: Microsoft® Office 2007 Basic, Microsoft® Office 2007 Professional, Microsoft® Office 2007
Small Business, Microsoft Internet Explorer with Google Toolbar
On some models only (not included with FreeDOS): HP ProtectTools Security Software Suite Version 4.0, HP Power Manager, HP Firefox Virtual Browser, HP
Backup and Recovery Manager, HP Insight Diagnostics Software (available via HP Backup and Recovery Manager), Computer Setup Utility, McAfee AntiVirus
trial version, Roxio Creator Business 10 or DVD 10 or Easy Media Creator 9.0, Intervideo WinDVD 8 LE, PDF Complete
Input devices HP Standard Keyboard (PS/2 or USB) or HP USB Smartcard Keyboard
HP PS/2 2-Button Optical Scroll Mouse, HP USB 2-Button Optical Scroll Mouse or HP USB 2-Button Laser Scroll Mouse
Dimensions (w x d x h) 17.7 x 45.2 x 44.7 cm 33.7 x 37.8 x 10.0 cm 25.1 x 25.4 x 6.6 cm
Power 365 watts maximum
Input voltage 90 – 264 / 100 – 240 VAC, 50/60
Hz, 47 – 63 Hz, active PFC (85% High Efficiency)
240 watts maximum
Input voltage 90 – 264 / 100 – 240 VAC, 50/60
Hz, 47 – 63 Hz, active PFC (85% High Efficiency)
135 watts maximum
Input voltage 90 – 264 / 100 – 240 VAC, 50/60
Hz, 47 – 63 Hz, active PFC (87% High Efficiency)
Warranty Protected by HP Services, including a 3-3-3 standard warranty delivering 3 years of parts and 3 year of both labour and on-site repair. Response time is next
business-day and includes free telephone support 24 x 7. Terms and conditions vary by country. Certain restrictions and exclusions apply
© 2008 Hewlett-Packard Development Company, L.P. The information contained herein is subject to change without notice. The only warranties for HP products and services are set forth in the express warranty statements accompanying such products
and services. Nothing herein should be construed as constituting an additional warranty. HP shall not be liable for technical or editorial errors or omissions contained herein.
Certain Windows Vista® product features require advanced or additional hardware. See http://www.microsoft.com/windowsvista/getready/hardwarereqs.mspx and http://www.microsoft.com/windowsvista/getready/capable.mspx for details.
Windows Vista® Upgrade Advisor can help you determine which features of Windows Vista® will run on your computer. To download the tool, visit www.windowsvista.com/upgradeadvisor.
Intel, Core and Pentium are registered trademarks of Intel Corporation or its subsidiaries in the United States and other countries. Microsoft and Windows are U. S. registered trademarks of Microsoft Corporation. Windows Vista® is either a registered
trademark or trademark of Microsoft Corporation in the United States and/or other countries.
For more information, please visit www.hp.com/eur/desktops
4AA2-1115EEE. November 2008
